230w 7R Sharpy Beam Moving Head Lights Stage Lights FD-DM230

Share to:
230W 7R bulb
0-100% linear dimming
Combined optical lens
Electronic focus
Rainbow effect
  • FD-DM230
  • Fondlites

Light Sources

Bulb: 230 bulb


Power Supply

Voltage:AC100-240V  50-60Hz

Power :320W

Optical System

Optics: High-precision combined optical lens.

Dimmer: 0-100% linear dimmer

Focus: electronic focus

Strobe: 1-20 times/second

Color: 1 fixed color wheel, 14 colors + white light, rainbow effect speed adjustable, half-step color effect

Gobo: 1 fixed gobo wheel, 17 gobos + white light, bidirectional variable speed rotation

Prism disk: built-in 1 effect prism, can be rotated forward and reverse.


Horizontal scan: 540°

Vertical scan: 270°


Control:DMX512, Auto-run, master/slave,RDM

Channels: 14 channels

Display mode: LCD display


DMX connector: 3PinXLR

Working Environment

Working temperature: -20-40℃

IP rate: IP20

230w 7R Sharpy Beam Moving Head Lights Stage Lights

230w 7R Sharpy Beam Moving Head Lights Stage Lights1

230 4

230 3

*1 fixed color wheel with 14 color chips, half color effect, linear color conversion and bidirectional variable speed rotating rainbow effect

*Independent atomization effect, soft and natural light spot

*Adopting a three-phase motor not only provides fast and smooth scanning and eliminates transmission noise

*Using wind direction drainage and temperature intelligent monitoring technology, according to the temperature of different positions of the lamps, the cooling fans in different parts of the lamps are automatically driven to effectively cool the lamps and lanterns.

*Using high-precision glass optical lens, electronic linear high-definition adjustment

*Using today's advanced technology to realize the remote sleep function, when the lamp is disconnected from the signal, it will automatically enter the sleep state, making the lamp more stable and safer, and you can set the sleep time by yourself.
