DMX512 Timing Relay Pack +Smart Switch FD-CP08

Share to:
Rated output power of each circuit:1000W

Dmx512 timing replay pack function

Smart switch function
Support Manual mode
Support DMX512signal control mode
Support RS485signal control mode

Maximum current of input line with plug:25A

Maximum current of bare input line:40A

Input Voltage:90-240V/50-60Hz

Rated output power of each circuit:1000W

Dmx512 timing replay pack function:Have

Smart switch function:Have

Manual mode:Support

DMX512signal control mode:Support

Channel mode supported by DMX512 mode:2/8/10ch

RS485signal control mode:Support

Power output base:Universal power base (default)

Installation dimension:Standard 19 inch 1U cabinet

Installation mode:3 kinds (cabinet, lamp hook, screw fixation)

DMX512 Timing Relay Pack +Smart Switch FD-CP08


"DMX512 Timing Relay Pack+Smart Switch" is a new power management product. It combines the function of timing device and intelligent switch control function, and supports a variety of control modes. Through the different combination of timing function and intelligent switch function, it can meet a variety of field application requirements.

Many devices such as smart hotels, smart homes, smart conference rooms and so on do not support remote signal control. The remote control function of these devices can be realized through the smart switch function to make non smart devices intelligent.
