19x40W Bee Eye RGBW Waterproof Wash Moving Head Light IP65 FD-LW1940B


Share to:
19*40W Osram RGBW LED
LED Lifespan: 50,000 hours
Advanced optical system
Protocols: DMX512, RDM
Beam Angle: 3.5°to 50°
Waterproof IP65
  • FD-LW1940B

  • Fondlites

Light Source
Light Sources: Powerful 19*40W Osram RGBW LED
LED Lifespan: 50,000 hours


Input Voltage: 100-220V, 50/60Hz

Power Consumption: 640 W

Optical system
Advanced optical system
Beam Angle: 3.5°to 50°

Control and Program
Display: LCD display
Protocols: DMX512, RDM
DMX Channel:  21/23/35/78/92/97/99ch

Firmware Upgrade: Upgrade via DMX link
Pan/Tilt Resolution: 16 bit

Pan & Tilt
Pan movement: 540°
Tilt movement: 270°
Automatic Pan/Tilt position correction


Rich Color, 65536 Level Dimming

Data In/Out: 3pin or 5-pin XLR, True One connector

Work environment
Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C
Protection Rating: IP65

Product Size:434*298*530mm
Product Weight: 22 kg

Flight Case Size:800*495*720mm

Flight Case Weight:74kg

19*40W LED Waterproof Zoom Wash Moving Head Light IP65

19pcs 40W Waterproof Par Light RGBW 4in1 LED Outdoor Light

Fondlites FD-LW1940B is an IP65 rated RGBW Osram LED moving head, a high-power outdoor wash light. This model is fitted with 19*40W Osram LED with a output of almost 100,000 lumens at 15 meters. It features a wide wash range from 3.5°to 50°, 16 bit dimming,with four optional dimming curve models, pixel effects and RDM compatibility.

Its new heat dissipation structure which combines technology of water cooling and semiconductor refrigeration allows for rapid heat dissipation from the working temperature. Thanks to the high efficient heat dissipation the metal structure could be replaced with lighter and stonger industrial plastics, bringing the overall weight to 18.7kg. Instead of using the traditional waterproof glue with associate potential risks.

FD-LW1940B is a waterproof fixture with a snap-in structure in order to ensure the integrity of the internal components. This fixture could be used for large stadiums, large performances and other professional venues and all-weather environment.
