FD-IWD600Z
Fondlites
Led Source
Light Source: 600W Color White LED
Color Temperature: 6600K
Average LED Life: 20,000 Hour
Power
Input Voltage: 100-240V AC, 50/60Hz
Power Consumption: 750W
Optical System
Zoom: 5° – 50° linear electronic
Prism(selectable): 4-facet circular rotating prism
Focus: Motorized linear focus
Strobe: 0-25Hz variable speed, pulse and random strobe
Dimmer: 0-100% variable linear dimming curves
Colors
6 Dichoric Colors plus open, Index / Bi-directional rotating rainbow effect
Rotating gobos
1 rotation gobo wheel with 6 interchangeable glass gobos plus open or 7 interchangeable glass gobos
Interchangeable rotating / Shake / Bi-directional variable-speed rotation effect
Glass gobo outside Φ28mm, insideΦ19mm
Water Dynamic effect
2 independent Water Streak glass wheels, two directional reciprocating rotation
Control&Connection
DMX Channel: 13CH
Control Mode: DMX, Auto, Sound, Program, Manual
Full Color 180° Reversible LCD
DMX In/Out: 3 pin waterproof signal cable
Power In/Out: 3 pin waterproof power cable
Construction
Protection Rate: IP65
Body Finish: Aluminum alloy shell with high strength, surface blasting oxidation treatment, black and gray optional or customized color is available
Cooling System: The heat pipe and advanced cooling system make the chip cool all the time, which maximize the chip illuminance and delay its life greatly
Packages
Net Weight: 26.20kg
Gross Weight: 29.10kg
Product Dimension: 262×321×544mm
Package(Carton): 335×422×807mm
