FD-DW480B
Fondlites
Light source
Light Sources: Philips 460w lamp
Lifespan: 2000hours
Power
Input Voltage: 100-220V, 50/60Hz
Power Consumption: 580 W
Optical system
Advanced optical design to ensure precise gobos and colors
Diameter of frontal lens: 186 mm
Beam Angle: 0°-2°
Control and Program
4-buttons touch panel
Display: LCD display
Protocols: DMX512, RDM
DMX Channel: 16/24
Firmware Upgrade: Upgrade via DMX link
Pan/Tilt Resolution: 16 bit
PAN & TILT
Pan movement: 540°
Tilt movement: 270°
Automatic Pan/Tilt position correction
Static Gobos
11 high-precision gobos, plus 1 open
Color Wheel
Color Wheel 1: 12 colors plus open
Connectors
Power In/Out：Power Connector in/out
Data In/Out: 3pin or 5-pin XLR, True One connector
Work environment
Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: -25°C
Protection Rating: IP65
Packages
Product Size:705*326 *419mm
Product Weight: 34.85 kg
Flight Case Size:935 * 326 *473mm
Flight Case Weight:71kg
