FD-LM580BSW
Fondlites
Led Source
Light Source: 580W White LED
LUX：5M@128000LX
Average LED Life: 20,000 Hours
CRI : Ra＞75
Power
Input Voltage: 100-240VAC, 50/60Hz
Power Consumption: 600W
Optical system
Zoom: 3° - 45°linear motorized
Frost: Frost filter hybrid wash effect
Strobe: 0-25Hz variable speed, pulse, and random strobe
Dimmer: 0-100% variable linear dimming curves
COLOR 8 Dichoric Colors plus open, Index / Bi-directional rotating rainbow effect
CMY + CTO Color mix system
1 fixed gobo wheels with 12 metal gobos plus open
Shake / Bi-directional flow effect ROTATING GOBOS
1 rotation gobo wheels with 7 interchangeable glass gobos plus open
Interchangeable rotating / Shake / Bi-directional variable-speed rotation effect
1 extra animation disk
Prism system：standard single six row prism and 8 prism, each prism can be independent positive and negative direction
Control
DMX Channel: 22/26CHs
Control Mode: DMX, Manual
Display: Full Color 180° Reversible LCD
Construction
Housing Material: Die-casting Aluminum
Housing Color: Black
Connection
3 pin or 5pin DMX In/Out
Powercon: Power Input+Output
Package
Net Weight: 23.5kg
Lamp size：380*274*700mm
Package size：750*360*470mm
Led Source
Light Source: 580W White LED
LUX：5M@128000LX
Average LED Life: 20,000 Hours
CRI : Ra＞75
Power
Input Voltage: 100-240VAC, 50/60Hz
Power Consumption: 600W
Optical system
Zoom: 3° - 45°linear motorized
Frost: Frost filter hybrid wash effect
Strobe: 0-25Hz variable speed, pulse, and random strobe
Dimmer: 0-100% variable linear dimming curves
COLOR 8 Dichoric Colors plus open, Index / Bi-directional rotating rainbow effect
CMY + CTO Color mix system
1 fixed gobo wheels with 12 metal gobos plus open
Shake / Bi-directional flow effect ROTATING GOBOS
1 rotation gobo wheels with 7 interchangeable glass gobos plus open
Interchangeable rotating / Shake / Bi-directional variable-speed rotation effect
1 extra animation disk
Prism system：standard single six row prism and 8 prism, each prism can be independent positive and negative direction
Control
DMX Channel: 22/26CHs
Control Mode: DMX, Manual
Display: Full Color 180° Reversible LCD
Construction
Housing Material: Die-casting Aluminum
Housing Color: Black
Connection
3 pin or 5pin DMX In/Out
Powercon: Power Input+Output
Package
Net Weight: 23.5kg
Lamp size：380*274*700mm
Package size：750*360*470mm
